CHAPTER 2 STANDARDS AND ADJUSTMENTS
2-15
8) Hook the longer cable [14] on the cable hook [18]; then, secure its end to the left side with
adhesive tape [19].
Be sure that the secured end of the cable is found where the hole in the left side plate and the tip
of the cable matches.
Figure 2-26
[18]
[19]
[14]
