CHAPTER 2 STANDARDS AND ADJUSTMENTS
2-17
3) Lead the longer end [5] under the No. 1 mirror mount [7]; then, hook it on the pulley [8] of the No.
2/3 mirror mount, and lead it between the No. 1 mirror mount [7] and the scanning lamp [9].
Figure 2-29
4) Hook the end of the longer end [5] on the hole [10] on the right side.
Figure 2-30
[5]
[7]
[8]
[9]
[5]
[10]
