CHAPTER 2 STANDARDS AND ADJUSTMENTS
2-29
3) Turn on the machine, and place the test sheet prepared in step 1) on the original tray.
Figure 2-50
4) Press the Copy Start key to make a copy.
5) Check to make sure that the distance L3 on the copy image indicated is 10 ±2.5 mm (standard)
or less.
Figure 2-51
Copy image
L3
L3=10 ± 2.5mm
