CHAPTER 2 STANDARDS AND ADJUSTMENTS
2-30
6) If the distance is not as specified, loosen the pinion gear positioning screw under the original
tray, and adjust the position of the pinion gear.
Figure 2-52
Relationship between Pinion Gear Position and L3
Table 2-4
Direction of pinion gear
A
B
L3
Increases
Decreases
Pinion gear positioning
screw
Pinion gear
A
B
