Components Guide
41
Control Dial
Turning the control dial allows you to perform
operations such as choosing items or
switching images. Except for a few
operations, the same operations are possible
with the opqr buttons.
Screen (LCD Monitor) (pp. 42, 159, 161)
0 (Face Selector) Button (p. 84)
1 (Playback) Button (pp. 26, 109)
DC IN (Power Input) Terminal (p. 153)
A/V OUT (Audio/Video Output) / DIGITAL
Terminal (pp. 34, 117, 134)
b (Exposure Compensation) (p. 68) /
a (Single Image Erase) Button (p. 27)
- (p. 72) / d (Jump) (p. 111) / o Button
e (Macro) (p. 69) / f (Manual Focus)
(p. 86) / q Button
Control Dial
m FUNC./SET Button (p. 44)
h (Flash) (pp. 69, 88) / r Button
Q (Self-Timer) (pp. 57, 76, 77) / p Button
Indicator (p. 43)
l (Display) Button (p. 42)
n Button (p. 45)
