162
External Device Input
[External Device Input Event]
Select whether to use the input from an external device, such as a connected sensor, as an event.
External Device Input 1, 2
You can set the operation to be performed when an event is triggered by input from an external device.
The camera has two external device inputs. You can set the input for each of them.
You can set these if you have selected [Enable] in [External Device Input Event].
An icon in the [Event and Input/Output] menu of the Camera Viewer will indicate when there is an external device input event (P.84).
[Operation Mode]
Select the circuit condition to suit the signal input from the connected external device.
When [Normally Open] is set, an active event occurs when the terminals of the external device close, and an inactive event
occurs when the terminals open.
When [Normally Close] is set, an active event occurs when the terminals of the external device open, and an inactive event
occurs when the terminals close.
[Active Event Operation]
Select the operation to be performed when an active event is triggered.
If [Enable] is set, [Preset], [Video Record] and [E-mail Notification] will be executed according to their settings when an
active event is triggered.
[Inactive Event Operation]
Select the operation to be performed when an inactive event is triggered.
If [Enable] is set, [Preset], [Video Record] and [E-mail Notification] will be executed according to their settings when an
inactive event is completed.
[Ongoing Active Event Operation]
Select the operation to be performed during an active event. This can only be set when [Active Event Operation] is set to
[Enable].
If [Enable] is selected, [Video Record] and [E-mail Notification] will be executed according to their settings during the active
event.
[Preset]
If you specify a preset, the camera angle will automatically move to the preset location when an external device input event
is triggered.
It is necessary to set presets beforehand with [Camera] > [Preset] (P. 131).
[Video Record]
Select whether to record video depending on the event.
If you select [Enable] and an external device input event is triggered, video will be transmitted to the recording destination
specified in [Video Record] > [Upload] > [Video Record Action] (P. 156).
[E-mail Notification]
Select whether to send an e-mail notification depending on the event.
If [Enable] is selected, e-mail notification will be performed when an external device input event is triggered.
To use e-mail notification, you must set [Video Record] > [E-mail Notification] (P. 160) beforehand.
[External Device Output for Active Event]
Select whether external device output (1 or 2) is active or inactive when an active event is triggered.
[External Device Output for Inactive Event]
Select whether external device output (1 or 2) is active or inactive when an inactive event is triggered.
[Audio Playback at Active Event]
If you select [Enable], the sound clip specified in [Sound Clip] will play back at active events for the external device input.
When the camera is moved to a preset position specified in the [Preset] settings, camera control privileges are released, even if the user
has obtained those camera control privileges using the Camera Viewer or other camera control applications.
R13
M50R13
