Using the Wind Screen

With the supplied microphone (only), you can reduce the sound of wind recorded from the front

microphone.

Open the menu and select [AUDIO SETUP]. Select [WIND SCREEN], select a setting

option and close the menu.

Recording on Channels 1 and 2

Select the audio input from FRONT MIC (supplied microphone), AUDIO1 (RCA terminals) or REAR

(XLR terminals). Refer also to the Audio Block Diagram ( 157).

When Using the Front Microphone

Set the INPUT SELECT switch to FRONT MIC.

• You can select the microphone setting with the STEREO/MONO switch on the microphone itself. In the

MONO position, the same monaural audio signal will be recorded on channels 1 and 2.

• If necessary, turn on the microphone attenuator (20 dB) by setting the FRONT MIC ATT. switch to ATT.

When Connecting to the RCA terminals of AUDIO1 (Line-in Recording)

1. Connect the device to the RCA terminals of AUDIO1.

2. Set the INPUT SELECT switch to AUDIO1.

( 31)

AUDIO SETUP WIND SCREEN•••ON
