42
English
Note:
• The selection of the speaker type must always be confirmed with the „OK“
button, otherwise your selection will not be stored.
5
Now, go back one menu level by pressing the „M“ button. There, select the
item „Speaker Mapping“ [SPM] and press „OK“.
6
Select the appropriate speaker (Front Left, Front Right, Center, Sub, etc.)
and confirm with „OK“.
• If you want to connect passive speakers (large/small) by a speaker cable,
select Analog1 to Analog5 (corresponding to the speaker output 1 to 5 of
the Amp 5.1) using the „+/−“ keys and exit the menu item by pressing the
„OK“ button. Analog6 can only be used for subwoofers.
• If you have selected Smart speaker in the Speaker Config [SPC] menu,
pressing the „OK“ button will initiate the pairing process. „Pairing in
Process“ appears on the TV screen and the message „Wireless“ behind
the selected speaker changes to „Wireless(PIR)“. The LED display shows
[PIR], too.
7
Now, plug the mains cable of the (new) loudspeaker to be connected into
the mains socket and/or switch it on using the mains switch (if present).
Before, this speaker must have been disconnected from the mains for
at least 30 seconds, otherwise pairing is not possible!
8
Approx. 10–20 seconds after connecting the speaker to the mains and/or
switching it on, the TV screen will display „Pairing Successful“ and
„Wireless(CON)“ behind the selected speaker to confirm a successful pairing
process. The LED displays also show [CON].
9
If the connection process fails, „Pairing Failed“ appears on the TV screen and
„Wireless(FAI)“ appears behind the selected speaker. The display also shows
[FAI]. In this case, repeat steps 6 and 7 and make sure that the speaker to be
paired has been disconnected from the mains for at least 30 seconds before
initiating the pairing process by pressing the „OK“ button.
