106
English
HDMI CEC [CEC]
Consumer Electronics Control is a cross-market standardized protocol for controlling devices connected to the HDMI® inputs/outputs. By
default this function activated [ON].
The CEC functions supported by the Smart Connect 5.1 are:
- One touch Play: By pressing the “Play” button of e.g. a Blu-Ray player the Connect 5.1 switches on automatically and changes to the
corresponding HDMI® input.
- System Standby: With the TV switched on and then turning it into standby mode by pressing the “Power” key the Connect 5.1 also
goes automatically into standby mode.
Note: Depending on the programming of the TV device, the Connect 5.1 can also be automatically activated with the TV.
- Volume/Mute:
The volume of the Connect 5.1 can be operated using the Mute and Volume buttons of the TV remote control.
To activate/deactivate this function please proceed with the following steps:
1
To enter the menu, press and hold the input select key " " for at least 3 seconds.
2
Use the "+" resp. the "–" key to select the menu item System Setup [SYS] and confirm with the "Play/Pause" button " ".
3
Use the "+" resp. the "–" key to select the menu item HDMI CEC [CEC] and confirm with the "Play/Pause" button " ".
4
Use the "+" resp. the "–" key to select "OFF" [OFF] to disable the CEC function resp. "ON" [ON] to enable the function.
5
Confirm and exit the menu item by pressing the Input-button " ".
Notes:
•Many device manufacturers have developed their own protocols for controlling their devices based on the CEC standard. This can
mean that the functions described above only function partially or does not function at all.
•In order to avoid conflicts when controlling the Smart Connect 5.1, the “Volume +/–“, “Mute” and “Power” buttons on the TV
remote control should not be learned through the IR learn function of the pre-amplifier when using the CEC function. Delete the
codes if necessary.
