PRODUCT NO. 088-1760-6
ASS E MBLY
X6X4X2
R1
R2
BB
R1
R2
R3
CC
BB
R3
X1
CC
R1
Step 34
Requires R1, R2, R3, BB, CC
34a) Attach Big roof left cover (R1) to the left end of gazebo using M6x15
screws (CC) and M6 washers (BB). Similarly attach the Big roof right cover (R2)
to the right end of the gazebo.
34b) Attach Big roof middle cover (R3) between covers (R1 & R2) on the long
side using M6x15 screws (CC) and M6 washers (BB).
BB
CC
