Canvas 088-1760-6 User Manual

10 11
PRODUCT NO. 088-1760-6
ASS E MBLY
E2
E3
E1
AA
AA
BB
BB
Step 5
Requires E1, E2, E3, AA, BB, Z
Insert Decorative groove for long side (E1) and Decorative groove for short side
(E2) into each Decorative groove for corner (E3) using M6x15 bolts (AA) and M6
washers (BB). Tighten the bolts using the wrench (Z).
Step 4
Requires A, H1, BB, DD
Attach each Lower beam connector 1 (H1) to the top of each Post (A) using
M6x25 screws (DD) and M6 washers (BB).
DD
D2
D1
A
DD
H1
DD
DD
BB
DD
BB
Z
AA
