Canvas 088-1760-6 User Manual

12 13
PRODUCT NO. 088-1760-6
ASS E MBLY
J1
H2
AA
BB
J2
BBFF
F2
O
BB
GG
Step 10
Requires H2, J1, J2, AA, BB, Z
Attach Lower beam connector 2s (H2) to Frame for long and small side under
big roofs (J1, J2) using M6x15 bolts (AA) and M6 washers (BB). Tighten the bolts
using the wrench (Z).
BB
Z
AA
Step 11
Requires F2, O, BB, FF, GG
Attach one end of each Slanting bar for small roof (F2) to the Connector for small
top (O) using M6x55 screws (FF), M6 washers (BB) and M6 nuts (GG). Note: 2
single ends of the Slanting bar for small roof (F2) are attached to each end of the
Connector for small top (O).
FF
GG
BB

Canvas 088-1760-6 Specifications

General

Brand	Canvas
Model	088-1760-6
Category	Outdoor Furnishing
Language	English
