ASS E MBLY
Step 8
Requires A, V, D1, D2, BB, EE
Attach the lower end of Arc supports (V) to Posts (A) and upper end of Arc
supports (V) to beams (D1, D2) using M6x45 bolts (EE) and M6 washers (BB).
Step 9
Requires J1, J2, AA, BB, Z
Attach Frame for short side under big roofs (J2) to Frame for long side under
big roofs (J1) using M6x15 bolts (AA) and M6 washers (BB). Tighten the bolts
using the wrench (Z).
J2
J1
BB
AA
D1 D2
EE
V
A
BB
EE
Z
BB
BB
Z
AA
