Instruction manual BXC611 BXC911
12
Please keep this instruction manual for future reference
Secure the body with security screws, use 2 x ST4x30mm screws.
Fix the one-way-valve to the air outlet of the cooker hood. Then, attach the exhaust pipe onto the
one-way-valve as shown below.
6
 






          

Exhaust pipe
Cooker hood
Instruction manual BXC611 BXC911
Please keep this instruction manual for future reference
12
Fix the one-way-valve to the air outlet of the cooker hood. Then, attach the exhaust
pipe onto the one-way-valve as shown below.
6
  






        
  

Exhaust pipe
Cooker hood
6
  






        
  

Exhaust pipe
Cooker hood
BXC611 _ BXC911.indd 12 18/05/2016 12:32

Secure the body with security screws,Use 2 pcs ST4x30mm screws.
Exhaust Pipe
Cooker Hood
Wall Plug
2PCS ST4 x 30mm
