20 Instruction manual C706G Please keep this instruction manual for future reference
REPLACEMENT OF BURNER INJECTOR
› Loosen the injector with a dedicated wrench (7). Fit the new injector, suitable for the required
gas type (see table ‘Burners and Injectors Specifications’).
› After you have converted the hob to another gas type, make sure you have placed a label
containing that information on the appliance.
› Adjust the reduced valve flow.
Burners Flame
Converting the hob from
LPG to natural gas
Converting the hob from
natural Gas to LPG
Regular Burners
Full flame
Replace the burner injector
according to the guidelines
on page 19
Replace the burner injector
according to the guidelines
on page 19
Saving flame
Loosen the adjustment
spindle (see fig 7) and
adjust the flame
Loosen the adjustment
spindle (see fig 7) and
adjust the flame
