Please keep this instruction manual for future reference Instruction manual CM465 / CM465SS / CM465GM
BUILDING IN
Please check the minimum dimensions necessary for the proper installation of the appliance. The
coffee machine must be installed in a column unit, which must in turn be fixed to the wall.
EN 38
INSTALLATION INSTRUCTIONS
Building in
Please check the minimum measures necessary for the proper
installation of the appliance. The coffee maker must be installed in a
column unit, which must in turn be fi xed to the wall.
850 mm
min.
560 mm
80 mm
min.
550 mm
min.
50 mm
min.
50
mm
min.
450 mm
560 mm
+
-
1
16
4
1
2
