4 - Features and Technical Data
Control panel - (Fig. 4.2)
1. Electronic clock/end cooking timer
2. Multifunction oven switch knob
3. Multifunction oven thermostat knob
4. Front left burner control knob
5. Rear left burner control knob
6. Central front burner control knob
7. Central rear burner control knob
8. Rear right burner control knob
9. Front right burner control knob
10. Rotisserie control knob
Fig. 4.1
3
1
34
1
2
Cooking hob - (Fig. 4.1)
1. Auxiliary burner (A) 1,00 kW
2. Triple-ring burner (TC) 3,50 kW
3. Semi-rapid burner (SR) 1,75 kW
4. Rapid burner (R) 3,00 kW
Fig. 4.2
A
U
T
O
12345 78910
6
14
