Instruction manual DD903BK & DD522BK
17
Please keep this instruction manual for future reference
ELECTRICAL CONNECTION
WARNING
Place the metal box containing the electronic components at a distance of no less than 65cm from
the hobs or in any case, 65cm from the suctioning surface of the cooker hood.
After having replaced the filters, reinstall the front stainless steel panel, otherwise the Downdraft
is not able to function.
NOTE
We recommend installing the metal box containing the electronic components at least 10cm
above floor level and at a suitable distance from all heat sources (e.g. ovens or hobs).
CAUTION
This appliance is fitted with an H05 VVF 3 conductor, 0.75 mm
2
(neutral, phase, and ground)
power cord. This can be connected up to a 220 - 240V monophase electrical network through a
CEI 60083 approved power socket, which must remain accessible after installation, in compliance
with installation regulations.
We decline any responsibility in case of accidents caused by a lack of ground connection or
incorrect ground connection. The appliance must be fed through a differential protection device
(RCD), with a nominal residual current not exceeding 30mA. If the power cord is damaged, call
Caple Service to avoid any risk.
WARNING
The downdraft connection to the electrical network must be carried out only by professional
and qualified technicians. The downdraft must be connected to a properly installed and suitable
electrical network. The electrical system must comply with VDE0100 standard.
DANGER
If the cooker hood presents any anomaly, disconnect the appliance or remove the fuse
corresponding to the appliance power disconnecting line.
If the appliance has no plug or if the plug is not easily accessible, then a device needs to be
fitted to cut it off from the electric network; this device must have an opening distance between
contacts on all poles of at least 3mm.
