Instruction manual DD780BK Please keep this instruction manual for future reference32
After mains voltage is applied, all displays are illuminated briefly. After this, the hob is in stand-by
mode and ready for operation.
The hob is controlled by pressing the appropriate electronic button. Each button pressed is
followed by a buzzer sound.
SWITCHING THE HOB ON
Switch the hob on by pressing the ON/OFF button
. All cooking zone displays will show a static
“0” and the bottom right dots blink. (If a cooking zone is not selected within 20 seconds, the hob
will automatically switch off).
SWITCHING THE HOB OFF
Switch the hob off at any time by pressing
. The ON/OFF button always has priority over the
switch-off function.
SWITCHING THE COOKING ZONES ON
Press the cooking zone selection button that corresponds to the zone you wish to use. A static dot
will be shown on the selected zone display and the blinking dots on all other zone displays will no
longer illuminate.
Select the temperature setting by using the increase power setting button
or decrease power
setting button . The zone is now ready to use. For faster boil times, select the desired power
level, then touch the ‘P’ button to activate the Boost function.
SWITCHING THE COOKING ZONES OFF
Select the zone you want to switch off by pressing the cooking zone selection button. Using the
button, turn the power down to “0”. (Pressing the and buttons simultaneously also
turns the power to “0”). If the cooking zone is hot, “H” will be displayed instead of “0”.
SWITCHING ALL COOKING ZONES OFF
To switch all the cooking zones off at once, press the
key. In the stand-by mode, a “H” will
appear on all cooking zones which are hot.
RESIDUAL HEAT INDICATOR
The residual heat indicator indicates that the glass ceramic area has a temperature that is
dangerous to touch. After switching off the cooking zone, the respective display will show “H”
until the corresponding cooking zone temperature is at a safe level.
