Caple DD925CO - Page 19

Instruction manual DD925CO
19
Please keep this instruction manual for future reference
EN
HOW THE COOKER
HOOD WORKS
A: Light ON/OFF key
The light switches on and off only when the
downdraft is fully OPEN/UP.
Pressing this button with the downdraft closed
will cause the downdraft to open and then the
light will switch on.
The button also serves to switch off the light if it
is on.
B: ON/OFF key
This starts the downdraft unit upward movement
and when it is fully open, it sets the second
extraction speed.
With the downdraft open/up: it switches off the
motor and if on, the light; then it retracts the
downdraft unit.
C: Key
This reduces the speed of the extractor motor
from the 4
th
speed until the motor switches
off, without closing the pull-out carriage.
D: Indicators
• This signals the speed setting, by only the
relevant LED switching on.
E: Key
This increases the speed of the extractor motor,
from 1st to 4th speed, without moving the extractor
panel.
F: Timer
9
After 10 minutes from its setup, it allows to stop
the motor , close the extractable unit and turn the
lights off, if on.
Push the key again to annul this function.
TECHNICAL DATA:
Alkaline battery powered: 12v mod. 27A
Operating frequency: 433.92 Mhz
Combinations: 4096
Max. consumption: 25mA
Operating temperature: -20° : +55°C
Standard con iguration.
If two cooker hoods-radio control system are in-
stalled in the same room or in the immediate vi-
cinity, each system may affect the operation of
the other, due to the fact that they have the same
code. Therefore it will be necessary to change the
code of one of the radio controls.
Generating a new transmission code.
The radio control is supplied by the manufacturer
with default codes stored. If you want to create a
new set of codes, proceed as follows: press and
hold the UP, STOP and DOWN buttons simulta-
neously for 2 seconds. After the LEDS light up,
press the UP and DOWN buttons within 5 secon-
ds. The LEDS will flash 3 times to indicate that the
process is completed.
WARNING: This procedure deletes all previously
stored codes.
Learning the new transmission code.
After changing the transmission code on the ra-
dio control, the cooker hood electronic control unit
must be made to set the new code as follows:
press the main Power Off button on the cooker
hood and then restore power to the electronic
control unit. Within the next 15 seconds, press
the Light button. This will ensure the control unit is
synchronized with the new code.
Warning:
The battery should be replaced every year to gua-
rantee the optimal range of the transmitter.
To replace the exhausted battery, take the plastic
lid off, remove the battery and replace it with a new
one, observing the correct battery polarities. Used
batteries should be discarded in special collection
bins.
