Caple RIF125 - Built-In Installation

19Instruction manual RiF125Please keep this instruction manual for future reference
BUILT IN INSTALLATION
NOTE:
The wooden cabinet the appliance is to be housed in must not be enclosed. The back wooden
panel of the cabinet must be removed completely. This is to allow sufficient air circulation to
cool down the condenser unit for energy efficiency.
DIMENSIONS
560mm
1225-1233mm
min 550mm
540mm
595mm
540mm
min. 50mm
1126mm
1224mm
1245mm
40mm
58mm
Ventilation
min 200cm² in plinth
