16 Instruction manual WDi3301 Please keep this instruction manual for future reference
1
2
3
SELECT THE LOCATION
WARNING:
› Stability is important to prevent the product from moving.
› Make sure that the product does not stand on the power cord.
The washer dryer must be placed in a location according to the below:
› Rigid, dry, and level surface (if not level, please make it level with reference to the following
figure “Adjust Legs”)
› Avoid direct sunlight
› Sufficient ventilation
› Room temperature is above 0°C
› Keep far away from heat resources.
› Do not install the washer dryer on carpeted floor.
ADJUST LEGS
WARNING:
› The lock nuts on all four feet must be screwed
tightly against the housing.
Level the appliance using the feet:
1. Turn the nut clockwise to release the screw.
2. Rotate the foot to raise or lower it until it touches
to the floor.
3. Lock the foot, screwing in the nut, until it tightens against to the bottom of the
washer dryer.
Check the washer dryer is steady using a spirit level or by pressing the four corners on top of the
appliance in sequence.
NOTE:
The 4 legs allow the height of the washer dryer to be adjusted from 825mm to a maximum of
835mm.
