14 Instruction manual WMi3001 & WMi3006 Please keep this instruction manual for future reference
1. Drain Hose connection to Drain Pipe
2. Drain Hose connection to Sink Drain Pipe
3. Drain Hose attached to Sink
4. Drain Hose Support
5. Water Inlet Pipe
6. Electrical Connection
NOTE
When using the outlet hose support, please install it like the above image. If the outlet hose is
too long, do not force it into the washing machine as it will cause abnormal noises.
When installing outlet hose, fit it properly with rope.
WARNING
Contact Caple Service should the power cord need replacement. Installation faults are not
covered by the manufacturers warranty.
1
2
3
4
5
6
