15Instruction manual WMi3001 & WMi3006Please keep this instruction manual for future reference
BUILT IN INSTALLATION
Before installing the washing machine, please read these built-in instructions carefully and keep
for future reference. This appliance has been designed to be built into the kitchen furniture. The
recess should have the dimensions as shown in the figure below:
WARNING
When installing the appliance into the kitchen, if possible, ensure the hoses are placed in either
of the two recesses on the back of the appliance. This will help to prevent the hoses from being
kinked or trapped.
DIMENSIONS
540mm
152.5mm
min. 825mm
600mm
595mm
560mm
825-835mm
