Spindle is nodding backward.
The rear edge is cutting deepest.
Spindle is nodding forward.
The front edge is cutting deepest.
Spindle yaw is counterclockwise.
The left edge is cutting deepest.
Spindle yaw is clockwise.
The right edge is cutting deepest.
