Cardale DC-650N - Carriage Quick Release

Page 6
3 Carriage quick release.
a. Pull cord ''a'' to disengage. Carriage re-engage remain disengaged. See fig. 3
b. Move red slider ''b'' in direction of arrow to re-engage carriage at next movement.
Start operator. See fig. 4.
fig. 3 fig. 4
A
B
