Cardale DC-650N - Sectional Door Installation

Page 8
©
- Fix adjustable door fitting bracket to
top section at the centre of the door.
- Install rail bracket on centre position above door.
Make sure there is at least 10mm clearance
between highest travel point of door and rail.
- Level and mount operator.
- Disengage carriage from chain or belt.
Door may only be moved with
moderate speed.
- Connect 2-piece adjustable operator
pull bar to door bracket.
Note:
Remove or disable all door locks
before installation!
A beam break is strongly recommended
for use with
sectional doors (available
separately).
!
ATTENTION
Sectional doors
min. 35 mm
10 mm
