FOR ALL OTHER DOOR TYPES PLEASE CONTACT YOUR DISTRIBUTOR!
e Make sure motorhousing and rail are mounted correctly and secured.
Strengthen where needed.
f Install light bulb.
Type E14, max. 40 Watt (not included).
! Attention: before you start Operator programming please make sure your
carriage is engaged to chain or belt and door arm is attached to door.
OPERATOR CONTROL PANEL INDICATIONS
Your automatic door operator is provided with an easy to read
LED display panel with 4 light icons and three program buttons.
Light icons
2 door fully open
4 door fully closed
6 operator impulse (slow flash when on vacation lock)
8 power on (230V)
Adjustment buttons
/ Program button “decrease” and CLOSE test button
& Program button “increase” and
OPEN test button
% Programming button
LEGEND
LED off i.e. 2
LED illuminated i.e. R
LED blinking i.e. H
LED rapid blinking i.e. ,
Button pressed % or & or /
Default setting: i.e.
8Q
7W
6E
54
3/8
