Cardale DC-800 - Set External Signal Lights; Programming Lighting; Programming External Light Relay Kit

Menu b
S
ET EXTERNAL
SIGNAL LIGHTS (
[/])
1. LED S blinks and all others are illuminated.
2. Use & or / to set the signal light function
LED A blinks: external signal will be illuminated
LED Q illuminated: external signal will blink
3. Press % to store and go to Menu c
Menu c
P
ROGR
AMMING LIGHTING (
{/})
1. LED D blinks and all others are illuminated.
2. Use & or / to set the signal light function
LED A blinks: operator light wil be illuminated during warning phase
LED Q illuminated: operator light will blink during warning phase
3. Press % to store and go to Menu d
Menu d
P
ROGRAMMING EXTERNAL LIGHT RELAY KIT
1. LED F blinks and all others are illuminated.
2. Use & or / to set the light function
LED A blinks: external light will be illuminated during lighting phase
LED Q illuminated: external light relay 30 seconds alarm signal on actuation
of the safety reverse device
3. Press % to store and to finish setting up the external light.
The LEDs will automatically turn off starting at LED 8 and ending at LED 1.
Operator is now in operational (normal) mode (recognizable by illuminated LED I)
and possible LED W (door fully open) or LED R (door fully closed).
8Q
72
63
54
External light 30 seconds alarm signal on actuation of the
safety reverse device
8A
72
63
54
External light will be illuminated during lighting phase
8Q
72
63
54
operator light will blink during warning phase
8A
72
63
54
operator light will be illuminated during warning phase
8Q
72
63
54
external signal will blink
8A
72
63
54
external signal will be illuminated
Page 20
