Page 22
! Attention: Observe local regulations!
Always lay mains cable (230V) and control wire (low voltage) seperately.
! Attention: Only operate garage door when certain there is no person or object
in garage door opening and travel path.
Initial operation
Power-operated windows, doors and gates for industrial or commercial use must be checked by a
specialist after installation and then regularly at intervals of 1 year minimum.
Maintenance
This garage door operator is virtually maintenance-free.
However, all movable parts of the door and operator system should be checked regularly and kept
in an easily movable condition.
The
OPEN and CLOSE automatic cut-out settings should be checked regularly.
The door must be running smoothly and regularly maintained.
Check the lifting regularly.
Cardale Doors Ltd.
Brackley
Northants
NN13 7EA
England
Tel: 01280 703022
Fax: 01280 702195
http://www.cardale.uk.inter.net
MAIN UK & EIRE DISTRIBUTOR:
DC-800N
Garage Door Operator
Connected loads:
230 V
250 W (in operation with lighting)
3.9 W (out of operation without lighting)
Door travel speed:
0.14 m/s with "soft" start and "soft" stop
Push and pull force:
800 N
Excess travel stop:
88 secs.
Lighting:
1 x 40 W E14
Control voltage:
Low voltage below 24 V DC.
Automatic timer:
With additional relay for signal lights
connection and photocell to monitor the
through-traffic area
(both items available as accessories).
Warning phase adjustable from 2 to 70
seconds.
Open phase adjustable from 5 - 255 seconds.
Automatic cut-out:
Electronic power limit through microprocessor
and power sensor.
Anti-Block system:
Through microprocessor and RPM sensor.
Device to prevent forced opening of door:
Electronic back-drive prevention by permanent
protection of the closed door position.
Door will automatic close after ca. 1cm
detected unauthorized reverse movement.
Protection category:
For dry buildings only.
TECHNICAL SPECIFICATIONS
