Carefree of Colorado Installation Manual Compass
070035-001r1 13
OPTIONAL WIRE COVERS
Two optional wire covers are available for the Compass.
For upper wire routing use the upper wire cover. The cover
slides into the channel from the top and over the wires.
For lower wire routing use the lower wire cover. The cover
snaps onto the bottom of the rear channel. The lower cover
is purchased in sets of two (2). These can be applied to both
arms for a balanced aesthetic appearance.
Slide Upper Wire Cover into
Channel and Over Wires
Push Lower Cover Over
End of Channel. Pins on Cover
Snap into Holes in Channel
Optional Upper Wire Cover
Optional Lower Wire Cover
Alt011
