COMPASS Installation Manual Carefree of Colorado
2 070035-001r1
COMPONENT CHECKLIST
I
TEM DESCRIPTION QTY NOTE
1
Arm Assembly, LH 1 1
2
Arm Assembly, RH 1 1
3
Roller tube Assembly Ordered Separately 1 1
4
Screw, Hex Washer Head #6 x 3/8 2
5
Hole Plug 4
6
Switch Kit ordered separately 1 3,
4
7
Wire Cover, Upper, Optional 1 5
8
Wire Cover, Lower, Optional 1 5
Notes: 1. Awning configuration is specified at time of order, including awning length, fabric, color etc. Check awning
assembly against original purchase order. Arms are configuration specific and are not interchangeable.
2. Attaching hardware is furnished by installer. Refer to "Mounting the Awning" for requirements.
3. Switch Kit (item 6) is ordered separately. OEM's may choose to furnish the control switch. The switch
must be a DC polarity reversing switch with dynamic brake. Not used with the BT12 Wireless Awning
Control System.
4. The BT12 Wireless Awning Control System is ordered separately. Refer to the sales literature for
available options with the system.
5. Wire Covers (7, 8) are optional and must be specified at time of order.
4
6
5
1 2
3
CO003
7
8
To Next Page
