Indications
The PleurX Pleural Catheter Kit (Cat. 50-7000B) and
the PleurX Drainage Kits (REF 50-7500 series and
R
EF 50-7510 series) are indicated for:
•
Intermittent, long term drainage of symptomatic,
recurrent, pleural effusion, including malignant
pleural effusion and other recurrent effusions that
do not respond to medical management of the
underlying disease
The devices are indicated for:
1) the palliation of dyspnea due to pleural
effusion
2) providing pleurodesis (resolution of the pleural
effusion)
Contraindications
Use of the PleurX Pleural Catheter Kit and the PleurX
Drainage Kit is contraindicated in the following
situations:
1. When there is a shift
>
2 cm in the mediastinum
towards the ipsilateral side of the effusion.
2. When the pleural cavity is multi-loculated, and the
drainage of a single loculation would not be
expected to provide relief of dyspnea.
3. When there is a coagulopathy.
4. When the pleural cavity is infected.
5. When the effusion is known to be chylous.
Proofed by: Date:
Dimensions checked: Copy checked:
12.5 cm 28 cm
25.5 cm
Catheter: 66.0 cm
Internal Portion External Portion
F
enestrations
Polyester
Cuff
V
alve
2
.225 cm
Lockable Access Tip
Drainage Line: 61 cm
Pinch Clamp
Luer Lock
PleurX Pleural Catheter
PleurX Lockable Drainage Line
(
2)
RC041264
McGaw Park, IL
Richard Cisneroz
04-05-12
361-26801
(
1)
Instructions for Use
K
it Contents
Preparation Components
2
ChloraPrep 10.5 ml Applicators
w
ith Hi-Lite Orange Tint
1 Fenestrated Drape
1
Filter Straw
3
Lidocaine HCl 1%, 5 ml Ampules
1
SafetyGlide Needle, 22 Ga. x 1 ½” (3.8 cm)
1 SafetyGlide Needle, 25 Ga. x 1” (2.5 cm)
1
CSR Wrap
Placement Components
1 PleurX Pleural Catheter, 15.5 Fr.
1
Safety Scalpel
1
Guidewire Introducer with Needle
2 Syringes, 10 ml
1
Point Lok Sharps Safety Device
1
J-tip Guidewire
1 Forceps
1 Dilator, 8 Fr.
1
Dilator, 12 Fr.
1
Peel-Away Introducer, 16 Fr.
1 Tunneler
Closing Components
1 Tweezer
1 Silk Suture, 2-0 Straight Needle
1 Absorbable Suture, 3-0 Curved Needle
Drainage Components
1 Drainage Line with Lockable Access Tip
1 Needle, 17 Ga. x 1” (2.5 cm)
1 5-in-1 Drainage Line Adapter
1 Alcohol Pad
1 Valve Cap
Dressing Components
6 Gauze Pads, 4” x 4” (10.2 cm x 10.2 cm)
1 Foam Catheter Pad
1 Self-Adhesive Dressing
PleurX Pleural Catheter Description
The PleurX Pleural Catheter consists of a fenestrated
silicone catheter with a valve mechanism and a
polyester cuff. A barium sulfate stripe runs the entire
length of the catheter. The valve is designed to
prevent the passage of air or fluid in either direction
unless it is accessed with the specifically matched
drainage line or vacuum bottles provided by
CareFusion.
To Next Page
