8
ENG
“EVD evolution” +030222041 - rel. 1.0 - 01.06.2008
Battery module (code EVBAT*****)
EVBAT00200 is an electronic device that guarantees temporary power
to the driver in the event of mains power failures. Supplied with a 12
Vdc lead battery, it delivers 22 Vdc to the driver for the time required
to completely close the electronic valve being controlled, while during
normal operation the battery is recharged. The complete module with
batteries (code EVBAT00300) and the box for batteries (code EVBATBOX*0)
are available.
EBVAT00200 Batteria 12 V
EVBAT00300
Fig. 1.c
Valve cable E2VCABS*00 (IP67)
Shielded cable with built-in connector for connection to the valve motor.
The connector code E2VCON0000 (IP65) can also be purchased on its
own, to be wired.
Fig. 1.d
