Carel FCM series User Manual

FCM electronic regulator Cod. +302235300 - Rel. 2.0 del 30/11/98
21
8.5 Parameters concerning digital inputs and output
C29: Multifunction digital input ID1
C29 indicates the function of the digital input ID1.
Access:
Keypad: if C50=1, 3 or 4 Ü + for 5” and password 77;
if C50=0 or 2 Ü the parameter can only be displayed..
Remote control: if C50=4 Ü press “ENABLE” and and ;
Modes: only when C00=0, 1, 2, 3
Operating range: from 0 to 5
C29=0 Ü input not used
C29=1 Ü external alarm and automatic reset (alarm with open input)
C29=2 Ü external alarm and manual reset (alarm with open input)
C29=3 Ü delayed external alarm and manual reset (alarm with open input; time-delay set by P28)
C29=4 Ü On/Off regulation (off when open input): when in the Off status, the analogue output will be immediately
disenergized (0 V)
C29=5 Ü energization of the 0÷10 V analogue output to 100%: when the input is closed, the analogue output is forced
to 0 V.
Default: C29 = 0 Ü input not used.
Note: if the function associated with the input ID1 is the same as that associated with the input ID2, ID1 has priority
C30: Multifunction digital input ID2
C30 indicates the function of the digital input ID2.
Access
Keypad: if C50=1, 3 or 4
Ü
+ for 5” and password 77; if C50=0 or 2
Ü
the param. can only be displayed.
Remote control: if C50=4 Ü press “ENABLE” and and ;
Operating range: from 0 to 5
C30=0 Ü input not used
C30=1 Ü external alarm and automatic reset (alarm with open input)
C30=2 Ü external alarm and manual reset (alarm with open input)
C30=2 Ü external alarm and manual reset (alarm with open input)
C30=3 Ü delayed external alarm and manual reset (alarm with open input): time-delay set by P28
C30=4 Ü On/Off regulation (off when open input): when in the Off status, the analogue output will be immediately
disenergized (0 V)
C30=5 Ü energization of the 0÷10 V analogue output to 100%: when the input is closed, the analogue output is forced
to 0 V.
Default: C30 = 0 Ü input not used
Note: if the function associated with the input ID1 is the same as that associated with the input ID2, ID1 has priority
C31: Multifunction (relay) digital output
C31 indicates the function of the relay digital output (if not differently used according to the selected operating mode).
Access:
Keypad: if C50=1, 3 or 4 Ü + for 5” and password 77; if C50=0 or 2 Ü the param. can only be displayed..
Remote control: if C50=4 Ü press “ENABLE” and and ;
Modes: not available when C00=8
Operating range: from 0 to 8
C31=0 Ü output not used (disenergized relay)
C31=1 Ü disenergized relay in the event of generic alarm
C31=2 Ü energized relay in the event of generic alarm
C31=3 Ü disenergized relay in the event of active analogue output
C31=4 Ü energized relay in the event of active analogue output
C31=5 Ü disenergized relay when the analogue output has its max. value (hysteresis 0.5 V)
C31=6 Ü energized relay when the analogue output has its max. value (hysteresis 0.5 V)
C31=7 Ü disenergized relay when the analogue output reaches its max. value; energized relay when the
analogue output reaches its min. value (On/Off regulation)
C31=8 Ü energized relay when the analogue output reaches its max. value; disenergized relay when the
analogue output reaches its min. value (On/Off regulation).
Default: C31 = 0 Ü output not used.
