9
ANTIGELO/RESISTENZE APPOGGIO Tipo Min. Max. U.M. Variazione Default Pres. DVNP Nuovo
ANTIFREEZE/SUPPORTING HEATERS Type Min. Max. M.U. Variation Default Presence New
A1 Set allarme antigelo/Bassa temperatura U A7 A4 /d 0.1 3.0 -----
Antifreeze/Low alarm set-point
A2 Differenziale allarme antigelo/bassa U 0.3 19.9 /d 0.1 5.0 -----
temperatura / Differential for antifreeze/low
temperature alarm
A3 Tempo bypass allarme antigelo/bassa U 0 150 sec 1 0 -----
temperatura all'accensione della macchina
in Inverno / Bypass time for antifreeze
alarm/Low ambient temperature when
turning on the unit in heating mode
A4 Set resistenza antigelo in raffreddamento U A1 rd /d 0.1 5.0 -----
Set-point for the activation of antifreeze
A5 Differ. resistenza appoggio in raffreddamento U 0.3 19.9 /d 0.1 1.0 -----
Differ. for antifreeze in cooling
A6 Sonda resistenze di appoggio F 0 1 flag 1 0 -----
Supporting heaters probe
A7 Limite set allarme antigelo F -40 122 /d 0.1 -40 -----
Limit antifreeze alarm set
A8 Set resistenza appoggio in riscaldamento U A1 rd /d 0.1 25 -----
Set-point for the supporting heater
A9 Differ. resistenza appoggio in riscaldamento U 0.3 19.9 /d 0.1 3.0 -----
Differ. for antifreeze supporting heater
AA Accensione automatica in antigelo U 0 2 flag 1 0 -----
Automatic start in antifreeze
0= non abilitata / not enabled
1=resistenze di appoggio e pompa accesi / support heaters and pump on
2=accensione automatica con temp. < SET allarme antigelo / automatic start when temp. < antifreeze alarm SET
ALLARME Tipo Min. Max. U.M. Variazione Default Pres. DVNP Nuovo
ALARM Type Min. Max. M.U. Variation Default Presence New
P1 Ritardo allarme di flusso dalla part. pompa U 0 150 sec 1 20 -----
Flowmeter down delayed when starting the pump
P2 Ritardo allarme di flusso a regime U 0 90 sec 1 5 -----
Flowswitch alarm delayed during normal operating
P3 Ritardo allarme B.P. da accensione compr. U 0 199 sec 1 40 -----
Low pressure alarm delayed at compr. start-up
P4 Attivazione del cicalino / Buzzer ON U015 min 1 0 -----
P5 Rispristino allarmi / Reset of alarms F04flag 1 0
P6
P7 Allarme di bassa pressione da sonda F 0 2 flag 1 0 ---P-
Low pressure alarm with pressure probes
P8 Tipo ingr. digitale 1-2 / Sel. of the digital input F011 flag 1 0 -----
P9 0=nessuno / 0=no device connected
1=flussostato con ripristino manuale / 1=flow controller with manual reset
2=termico con ripristino automatico / 2=thermal with automatic reset
3=estate/inverno / 3=cooling/heating remote selection
4=fine defrost da contatto / 4=defrosting-end from pressure controller
5=flussostato con ripristino automatico / 5=flow controller with automatic reset
6=termico con ripristino manuale / 6=thermal with manual reset
7=estate/inverno con ritardi dC e dd / 7=cooling/heating with delay dC and dd
8=estate/inverno selezionato da H6 / 8=cooling/heating selected by H6
9=estate/inverno con ritardi dC e dd selezionato da H6 / 9=cooling/heating with delay dC and dd selected by H6
10=segnalazione allarme con ripristino automatico / 10=alarm signal with automatic reset
11=segnalazione allarme con ripristino manuale / 11=alarm signal with manual reset
PA Selezione allarme bassa pressione F 0 1 flag 1 0 -----
Selection low pressure alarm
0=non attivo a compressore spento / 0=no activ with compressor OFF
1=attivo a compressore spento / 1=activ with compressor OFF
Pb Set allarme di alta temperatura U -40 199 /d 0.1 90 -----
High temperature alarm set
PC Ritardo allarme alta temp. all’accensione U 0 150 min 1 30 -----
High temperature alarm delayed at start-up
