Carel MPXone - Page 44

44
ENG
mpxone +0300086EN rel. 2.2 - 13.11.2023
Functions
Defrost outputs Evaporator probes Control
1 1 normal
2 1 defrost managed on two outputs with reference to the same evaporator probe
1 2 defrost managed on the same output with reference to the two evaporator probes (minimum
evaporation temperature)
2 2 defrost managed independently on the two evaporator circuits
Tab. 5.h
Code Description Def Min Max UOM User User terminal
/Fb Assign defrost temperature probe (Sd) - see /FA 2 -4 8 - S YES
/FF Assign defrost temperature probe 2 (Sd2) - see /FA 0 -4 8 - S NO
DOG Assign defrost digital output - see DOA 104- SNO
DOH Assign auxiliary evaporator defrost digital output - see DOA 004- SNO
Evaporator fans (par. DOI)
Once the digital output has been selected, the evaporator fan on/off is signalled by the the evaporator fan icon switching on/
off on the display. See the paragraph “Evaporator fans”
Code Description Def Min Max UOM User User terminal
DOI Assign light digital output serving the main on the secondary devices
- see DOA
204- MNO
Condensate drain heater (par. DOP)
During defrosting there may be frozen condensate on the bottom of the cabinet that prevents the water thawed from the
evaporator from being drained correctly. The digital output can be configured to manage the condensate drain heater function.
The heater is started on activation of the pump down stage and stays on throughout the defrost procedure, until the end of the
dripping phase. The heater can be activated by selecting a digital output with par. DOP.
Notice: the heater must be protected against overheating (e.g. thermal protector).
Code Description Def Min Max UOM User User terminal
DOP Assign drain heater digital output - see DOA 004- MNO
Anti-sweat heater (par. DOQ)
Select the digital output for demisting the glass (control with fixed activation, see the paragraph “Anti-sweat heaters”).
Code Description Def Min Max UOM User User terminal
DOQ Assign anti-sweat heater digital output - see DOA 004- SNO
Generic On/Off stage function (par. DOS)
elect digital output for configuring an ON/OFF function.
Code Description Def On OUOM User User terminal
DOS Assign digital output for stage ON/OFF function – see DOA 004- SNO
