pCO Sistema
Code: +030220336 - rel. 1.5 - 22/12/10
23
J22 ——— not connected
J22 NO-9 normally open contact, relay 9
J22 C9 common for relay 9
J22 NC-9 normally closed contact, relay 9
J24 NO-8 normally open contact, relay 8
J24 C8 common for relay 8
J24 —— not connected
J24 NO-7 normally open contact, relay 7
J24 C7 common for relay 7
J24 ——— not connected
J24 NO-6 normally open contact, relay 6
J24 C6 common for relay 6
J24 —— not connected
J24 NO-13 normally open contact, relay 13
J24 C13 common for relay 13
J6 NO-12 normally open contact, relay 12
J6 C12 common for relay 12
J6 —— not connected
J6 NO-5 normally open contact, relay 5
J6 C5 common for relay 5
J6 ——— not connected
J6 NO-4 normally open contact, relay 4
J6 C4 common for relay 4
J6 —— not connected
J6 NO-3 normally open contact, relay 3
J6 C3 common for relay 3
J5 NO-2 normally open contact, relay 2
J5 C2 common for relay 2
J5 —— not connected
J5 NO-1 normally open contact, relay 1
J5 C1 common for relay 1
J4 ID1 digital input 1
J4 ID2 digital input 2
J4 ID3 digital input 3
J4 ID4 digital input 4
J4 ID5 digital input 5
J4 IDCM1 common for digital inputs ID1-ID5
J3 ID6 digital input 6
J3 ID7 digital input 7
J3 ID8 digital input 8
J3 ID9 digital input 9
J3 ID10 digital input 10
J3 IDCM2 common for digital inputs ID6-ID10
J2 B1 analogue input 1 (NTC probe only)
J2 AVSS common for analogue inputs
J2 B2 analogue input 2 (NTC probe only)
J2 B3 analogue input 3 (NTC probe only)
J2 AVSS common for analogue inputs
J2 B4 analogue input 4 (NTC probe only)
J2 B5 analogue input 5 (active probe, 0/1 V or 4/20 mA or NTC)
J2 AVSS common for analogue inputs
J2 B6 analogue input 6 (NTC, active probe, 0/1V or 4/20 mA)
J1 B7 analogue input 7 (NTC, active probe, 0/1V or 4/20 mA)
J1 +24 Vdc 24 Vdc power supply for external active probes (max. current 100 mA)
J1 B8 analogue input 8 (NTC, active probe, 0/1V or 4/20 mA)
