23 “Power+” +0500048IE - rel 2.2 - 06.11.2014
ENG
5.1 Rated values
The table below shows the rated input and output values, as well as the specifi cations for sizing the cables (cross-
section, maximum length) and the fuses. The values refer to an operating temperature of 60 °C and a switching
frequency of 8 kHz, unless otherwise specifi ed.
Model
Rated input
current (*)
Fuse or type B
circuit breaker
Power cable
cross-section
Rated output
current
Rated output
power (**)
Max. total
dissipation
Max. heatsink
dissipation
Minimum
motor cable
cross-section
Maximum
motor cable
length
PSD10122*0 22 A 32 A 4 mm
2
12 A 4,5 kW 330 W 190 W 2,5 mm
2
5 m
PSD10162*0 28 A 40 A 6 mm
2
16 A 6,0 kW 450 W 250 W 2,5 mm
2
5 m
PSD10184*0 23 A 32 A 4 mm
2
18 A 10,5 kW 320 W 250 W 4 mm
2
5 m
PSD10244*0 30 A 40 A 6 mm
2
24 A 14 kW 485 W 380 W 4 mm
2
5 m
Tab. 5.b
(*) Rated input current is referred to input voltage of 230 Vac for single phase power supply drives (PSD 10**2**) and
to 400 Vac for 3phase power supply ones (PSD 10**4**). If voltage is lower than nominal, input current in drive code
PSD10122** and PSD10162** can increase up to 32 A.
(**) Rated output power is referred to following conditions:
• output voltage: 230 Vac for single phase drives, 400 Vac for 3phase ones
• rated output current
• cosφ 0.94 for single phase drives and cosφ 0.88 for 3phase ones
