Use a 25mm Single Hex
Socket when tightening or
removing ball cage
from Piston.
PARTS LIST
-
Piston Assembly
KEY
(Reverse for assembly)
LOCTITE
TORQUE
MAINTENANCE ORDER
GREASE INTERNAL
(AGMD-010)
GREASE
77-3311 R1.0 23/36 www.carlisleft.com
