7. Technical specifications:
Torque requirement Nm
M3 1.35
M4 3.3
M5 6.5
M6 11.1
E420
Weight - Basic
Weight - Circulation
Approx. 3.4 kg
Approx. 3.7 kg
Length 469.9 mm
Swivel height - Basic
Swivel height - Circulation
172.8 mm
201.8 mm
Mounting arrangement Robot mounting flange
Max working pressure 250 bar
Max working temperature 80° C
Material inlet Male 3/8” BSP connector
Material return Male 3/8” BSP connector
Air ports 8 mm
Minimum air pressure requirement
Maximum air pressure
5.5 bar
7 bar
Material leakage port 8 mm
