CARLO GAVAZZI VariFlex3 RVLF Series Quick Start Guide

Specications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network.18/11/2014 11
3.4. 200V Single phase (PNP input)
Motor Controllers AC Variable Frequency Drives Type Variex
3
RVLF
AC Power
source
L1(L)
S2
S3
S4
+
T1
T2
T3
S5
S1
-
Frequency
reference or PID
Multi-function input
Fuse
Inverter
output
Ground
E
Main
switch
Power
input
RS485
Pin1 to Pin 8
AO
AGND
+
-
L3(N)
RB
RA
Multi-function output
0~10V
CON2
10V
AVI (0~10V)
ACI (0~20mA)
AGND
AO
Relay output
250VAC/1A
(30VDC/1A)
M
1:Data+
2:Data-
3:Data+
4:Reserved
5:Reserved
6:Data-
7:5V
8:GND
+24V
Model:
200V: RVLFA120020F / RVLFA120040F / RVLFA120075F,
RVLFB120150F / RVLFB120220F
