CARLO GAVAZZI VariFlex3 RVLF Series Quick Start Guide

Specications are subject to change without notice. Pictures are just an example. For special features and/or customization, please ask to our sales network.18/11/2014 13
Motor Controllers AC Variable Frequency Drives Type Variex
3
RVLF
*P, BR for 400V series
Note: the screw on L2 terminal is removed for the single phase input supply models.
Single phase
Three phase (400V series)
3.5.1. Description of Main Circuit Terminals
3.5. Terminal Description
Terminal symbols TM1 Function description
L1 (L)
Main power input, L1 (L)/L2/L3 (N)L2
L3 (N)
P*
Externally connected braking resistor
BR*
T1
Inverter output, connect to U, V, W terminals of motorT2
T3
Ground terminal
L1(L) L2 L3 (N) T1 T2 T3
L1(L) L2 L3 (N) T1 T2 T3
L1 L2 L3 P BR T1 T2 T3
L1(L) L2 L3 (N) T1 T2 T3
L1(L) L2 L3 (N) T1 T2 T3
L1 L2 L3 P BR T1 T2 T3
