9
NOTE(S):
a. Steel Rod.
Table 4 — Torque Values (cont)
5H UNITS
SIZE DIA (in.) THREADS (per in.) RANGE (lb-ft) USAGE
1/16 Pipe 10-15 Pipe Plug - Auxiliary Control Valve Body
1/8 Pipe 15-20 Pipe Plug - Pump End Bearing Head
1/4 Pipe
20-25 Pipe Plug - Crankcase
20-25 Pipe Plug - Pump End Cover
20-25 Pipe Plug - Crankshaft
1/4 28 NF
12-16 Oil Pump Cover - Pump End Bearing Head
8-12 Auxiliary Control Valve Cover - Valve Body
8-12 Special Cap Screw - Auxiliary Control Valve Body
1/4 20 NC 8-10 Oil Pump - Bearing Head (12 cylinder)
5/16 18 NC
16-20 Oil Pump Cover - Pump End Bearing Head
16-20 Capacity Control Valve - Pump End Bearing Head
16-20 Auxiliary Control Valve - Pump End Bearing Head
16-20 Manifold Cover Plate - Crankcase
18-24 Oil Pump Adapter (12 cylinder)
5/16 24 NF
18-22 Unloader Power Element - Crankcase
18-22 Capacity Control Valve - Pump End Cover
18-22 Discharge Valve Guide Assembly - Valve Plate
18-22 Discharge Valve Guide - Inner Seat
18-22 Cylinder Bracket
3/8 Pipe
30-35 Pipe Plug - Pump End Bearing Head
30-35 Pipe Plug - Crankshaft
3/8 16 NC
25-29 Capillary Tube Assembly - Pump End Bearing Head
28 Connecting Rod Bolt (Aluminum Rod)
7/16 14 NC
35-60 Suction and Discharge Manifold Cover - Crankcase
55-60 Discharge Manifold - Cylinder Heads
55-60 Valve Plate - Crankcase
55-60 Cylinder Head - Crankcase
53-60 Hand-Hole Cover - Crankcase
55-60 Shaft Seal Cover
55-60 Pump End Cover and Pump End Bearing Head - Crankcase
7/16 20 NF 40-45 Connecting Rod Bolt - Locknut
a
1/2 Pipe
35-50 Pipe Plug - Crankcase
35-40 Pipe Plug - Pump End Bearing Head
30-35 Pressure Relief Valve - Suction and Discharge Manifold Cover
30-35 Pressure Relief Valve - Crankcase
1/2 13 NC
80-90 Suction and Discharge Manifold - Crankcase
80-90 Suction Manifold Cover - Crankcase
80-90 Pump End Bearing Head - Crankcase
80-90 Oil Filter Housing - Bearing Head
5/8 11 NC 140-150 Suction Manifold Cover and Suction Manifold - Crankcase
5/8 18NF
60-75 Magnetic Plug - Pump End Bearing Head
60-75 Modulating Valve Adapter - Crankcase
60-75 Oil Bypass Plug - Crankcase
60-75 Oil Bypass Plug - Pump End Bearing Head
60-75 Oil Bypass Plug - Pump End Cover
80-90 Hollow Lock Screw - Pump End Cover and Center Main Bearing Housing
18-22 Oil Pressure Regulator Valve - Crankcase
80-90 Cap-Oil Pressure Regulator Valve Assembly
7/8 14 NF
60-75 Seal Plug - Pump End Bearing Head
18-22 Oil Pressure Regulator Valve - Crankcase
3/4 Pipe 45-50 Pipe Plug - Crankcase
1 Pipe 50-55 Pipe Plug - Crankcase
1-1/2 18 NEF 35-45 Sight Glass Clamping Gland - Hand-Hole Cover
No. 6 32 8-10 Auxiliary Control Valve Cover - Valve Body
LEGEND
NC — National Coarse
NEF — National Extra Fine
NF — National Fine
