Carrier TRANSICOLD Vector 8500 Operator's Manual

45 62-11646
F USES - C ONTINUED
WARNING
!
When replacing fuses, lockout/tagout the power plug and the
negative battery cable.
*With EES installed F8 = 10 amp for FLS and EES
Fuse Purpose Amps Volts
F1 Module Logic Circuit and
Buzzer Power
5A 12VDC
F3 Stepper Valve Module
Component Actuation and
Engine Control Unit Power
5A 12VDC
F5 Power Enable Relay Contact
Power
30A 12VDC
F6 AutoFresh Air Exchange
Solenoid Power
10A 12VDC
F7 Main Power 80A 12VDC
F8* Fuel Level Sensor Power 5A 12VDC
F9 Contactor Control Board
Component Actuation Power
5A 12VDC
F10 Main Microprocessor Module
Component Actuation Power
20A 12VDC
F11 Light Bar Power 5A 12VDC
F12 Satellite Communications
Power
5A 12VDC
F14 Fuel Heater Power 15A 12VDC
F33, 34, 35 Battery Charger 5A (timed) 600VAC
F36, 37, 38 Condenser and Evaporator
Fan
Motors
12A 600VAC
F39, 40, 41 Coil/Drain Pan Heaters 12A (timed) 600VAC
