17/19EX Machine Familiarization (Figure 1, Figure 2, and Figure 3)
Machine Identification Label
The identification label is located on the right side of the machine control center panel. The
label contains information on model number, refrigerant charge, rated voltage, etc.
System Components
The components include the cooler and condenser heat exchangers in separate vessels,
motor-compressor, lubrication package, control center, utility vessel, and motor starter. All
connections from pressure vessels have external threads to enable each component to be
pressure tested with a threaded pipe cap during factory assembly.
Click here for Figure 1 — 17/19EX Identification
Click here for Figure 2 — Typical 17EX Installation
Click here for Figure 3 — Typical 19EX Installation
