Note: For medium voltage motors add 85 lbs (39 kg) to above for 60-Hz motors and 145 lbs (66 kg) for 50-Hz
motors. Total compressor/motor weight is the sum of the compressor, stator, rotor, and end bell cover
weight. Compressor weight includes suction and discharge elbow weights.
Table 1 — 19XL Compressor/Motor Weights
Motor
Size
English SI
Com-
pressor
Weight
(lb)
Stator
Weight (lb)
Rotor
Weight (lb)
End
Bell
Cover
(lb)
Com-
pressor
Weight
(kg)
Stator
Weight (kg)
Rotor
Weight (kg)
End
Bell
Cover
(kg)
60
Hz
50
Hz
60
Hz
50
Hz
60
Hz
50
Hz
60
Hz
50
Hz
CB
2660 1135 1147 171 233 250 1208 515 520 78 106 114
CC
2660 1143 1150 197 239 250 1208 218 522 90 109 114
CD
2660 1153 1213 234 252 250 1208 523 551 106 114 114
CE
2660 1162 1227 237 255 250 1208 528 557 108 116 114
CL
2660 1202 1283 246 270 250 1208 546 582 112 123 114
CM
2660 1225 1308 254 275 250 1208 556 594 115 125 114
CN
2660 1276 1341 263 279 250 1208 579 609 119 127 114
CP
2660 1289 1356 266 284 250 1208 585 616 121 129 114
CQ
2660 1306 1363 273 287 250 1208 593 619 124 130 114
CR
2660 1335 1384 282 294 250 1208 606 628 128 133 114
