Carrier 30HXA - Base Unit Dimensions, 30 HXA161-186 Units

DIMENSIONS — in. (mm)
UNIT
30HXA
ABCDEFGHJ
161
72.12
(1832)
50.63
(1386)
48.56
(1233)
46.62
(1184)
72.06
(1830)
51.00
(1295)
2.70
(69)
62.50
(1588)
35.20
(894)
171
61.37
(1559)
61.37
(1559)
43.25
(1099)
46.62
(1184)
61.31
(1572)
61.75
(1568)
2.70
(69)
62.50
(1588)
35.20
(894)
186
61.37
(1559)
61.37
(1559)
43.25
(1099)
46.62
(1184)
61.31
(1572)
61.75
(1568)
2.70
(69)
62.50
(1588)
35.20
(894)
Fig. 4 — Base Unit Dimensions, 30HXA161-186 Units
NOTES:
1. Denotes center of gravity.
2. Dimensions are in inches. Dimensions ( ) are in millimeters.
3. Recommended service clearance around unit (front, back, and one side) is
369 (914).
LEGEND
K.O. — Knockout
SAE — Society of Automotive
Engineers, U.S.A.
THK — Thick
TYP — Typical
5
