30RBP only
Power connection
Sizes 360-400
Option 116V/116W
1 2
1
2
1
1
1
1
1
1
All dimensions are in mm.
1
Clearances required for maintenance and air ow
2
Clearance recommended for coil removal
Water inlet
Water outlet
Air outlet, do not obstruct
Control box
NOTE: Non-contractual drawings.
When designing a system, refer to the certied dimensional drawings
provided with the unit or available on request.
For the location of xing points, weight distribution and coordinates of
the centre of gravity, refer to the certied dimensional drawings.
