Table 1 — VVT Bypass Controller Categories and Options
OPTION DESCRIPTION DEFAULT MINIMUM MAXIMUM
CATEGORY 1.0 SET POINTS
1.1 Cool-Down Set Point (F) 80 72 87
1.2 Warm-Up Set Point (F) 60 55 70
1.3 Fahrenheit Temperature Display ON OFF ON
CATEGORY 2.0 OCCUPANCY SCHEDULE
No configuration required.
CATEGORY 3.0 DAMPER
3.1 Maximum Damper Position 15 8 15
3.2 Minimum Damper Position 0 0 7
3.3 Pressure Sensor Error Damper Position 5 2 13
3.4 System Pressure Set Point (in. wg) 1.0 0.0 5.0
3.5 Stand Alone Operation OFF OFF ON
3.6 Changeover Cycle ON OFF ON
3.7 ZD/RD Actuator ON OFF ON
3.8 Counterclockwise Open ON OFF ON
3.9 Fan On Delay (sec) 120 0 600
3.10 Fan Off Delay (sec) 120 0 600
CATEGORY 4.0 HVAC EQUIPMENT
No configuration required.
CATEGORY 5.0 SENSORS
5.1 Room Sensor 1 1 3
5.2 Room Temperature Sensor Calibration (F) Zone Temp. — —
5.3 Remote Room Sensor Calibration (F) Room Temp. — —
5.4 Duct Temperature Sensor Calibration (F) Duct Temp. — —
5.5 Pressure Sensor Range (F) 2.0 0.0 5.0
5.6 Auto-Zero Enable OFF OFF ON
5.7 System Setup Enable OFF OFF ON
5.8 Pressure Sensor Calibration (in. wg) Duct Press. — —
5.9 Auto-Pressure Set Point OFF OFF ON
CATEGORY 6.0 SUPPLEMENTAL HEAT
No configuration required.
CATEGORY 7.0 DIAGNOSTICS/METERING
7.1 Error Code Display OFF OFF ON
7.2 Alternate Information OFF OFF ON
7.3 Unit Reset OFF OFF ON
CATEGORY 8.0 START-UP
8.1 Device Element Address 0 0 239
8.2 Security Level 1 1 4
8.3 Device Bus Number 0 0 239
CATEGORY 9.0 BROADCAST / DAYLIGHT SAVINGS TIME
No configuration required.
CATEGORY 10.0 HOLIDAY SCHEDULES
No configuration required.
CATEGORY 11.0 ALARM
11.1 Equipment Priority 7 0 7
11.2 Communication Failure Retry Time (Minutes) 10 1 240
11.3 Re-Alarm Time (Minutes) 30 1 255
CATEGORY 12.0 OPTIMAL START
No configuration required.
CATEGORY 13.0 LOADSHED
No configuration required.
CATEGORY 14.0 INDOOR-AIR QUALITY (IAQ)
14.1 Indoor-Air Quality Sensor OFF OFF ON
14.2 Indoor-Air Quality Pressure Set Point (in. wg) 0.0 0.0 5.0
14.3 Indoor-Air Quality Delay (min) 0 0 240
